Facilities




  • Software

    • ANSYS

      • Maxwell 2D/3D, Simplorer, RMxprt, PExprt

      • ANSYS mechanical FEA suite

      • ANSYS Icepak CFD

      • ANSYS thermal FEA suite

    • Infolytica MagNet FEA, MagSoft Flux 2D FEA

    • MatLab/Simulink with common toolboxes including SimPowerSystems

      • Real-Time Workshop (Texas Instruments DSPs)

  • Workstations

    • Xeon (12-core), 16GB, E5520, workstation

      • 3-D FEA and multiphysics problems

    • Xeon (8-core), 16GB, E5520, workstation

      • 3-D FEA and multiphysics problems

    • Xeon (4-core), 4GB, E5520, two workstations

      • 2-D FEA and multiphysics problems

  • Test equipment

    • S. Himmelstein & CO 2904T, Torque Transducer, 225 Nm, 10,000 r/min

    • Magtrol Model HD-800-8, Dynamometer /Torque Transducer, 12.00 Nm

    • Wayne Kerr 4300, LCR Meter, 20 Hz -1 MHz, 0.1% basic accuracy

    • Fluke 41B, Power Harmonics Analyzer, Voltage/Current/Power/THD/PF

    • Tektronix TDS 2024B 4-Channel Oscilloscope, 200 MHz, 2 GS/Sec

    • Tektronix TPS 2024B, 4-Channel Oscilloscope, 200MHz, 2 GS/sec

    • High Voltage Differential Probes (Tek P5200) and HP-1146A Current probes

    • National Instruments SCXI DAQ

  • Drive systems

    • Yaskawa V1000 ac drive, with constant V/f and sensorless vector control

    • Allen-Bradley (AB) PowerFlex 700 ac drive, with constant V/f and sensorless vector control

    • Programmable 15-kW IGBT voltage source inverter, 230/460V, 20A

    • Allen-Bradley (AB) Bulletin 1395, dc drive

    • Mitsubishi PWM-Voltage Source Inverter, including constant V/f controller

    • Allen-Bradley (AB) Bulletin 1336 PWM-Voltage Source inverter, including

constant V/f controller

  • Texas Instruments C2000 DSP controllers

    • Texas Instrument ezDSP Development Bundles, TMS320F2812, TMS320F28335

    • MATLAB Simulink Target Support Package C2000

  • Electric machines

    • Reconfigurable 3-phase, 230V, 3.5-hp, 6-pole, Interior Permanent Magnet A. O. Smith Synchronous Motor with three parallel winding paths per phase, and external access to the stator winding coils.

    • Reconfigurable 3-phase, 230/460-V, 5-hp, 60-Hz, 6-pole, Squirrel-Cage Induction Motor (Reliance Electric, rewound by Badger Corporation)

    • Tapped-winding, 3-phase, 230/460-V, 5-hp, 60-Hz, 6-pole, Squirrel-Cage Induction Motor (Reliance Electric)

    • 3-phase, 230/460-V, 5-hp, 60-Hz, 6-pole, Squirrel-Cage Induction Motor (Reliance Electric)

    • 3-phase, 230/460-V, 5-hp, 60-Hz, 4-pole, Squirrel-Cage Induction Motor (Reliance Electric)

    • 3-phase, 230/460-V, 2-hp, 60-Hz, 2-pole, Squirrel-Cage Induction Motor (A. O. Smith)

    • Tapped-winding, 3-phase, 230/460-V, 2-hp, 60-Hz, 2-pole, Squirrel-Cage Induction Motor, with four identical spare rotors (A. O. Smith).

    • Several 1.5-hp and fractional-hp, 3-phase, 230/460-V, 60-Hz, Squirrel-Cage Induction Motors plus several spare rotors (A.O. Smith and Reliance Electric)
